Ryobi OLP1832B - Replacing the Cutting Blade

14
Maintenance
3
2
1
5
2
1
1
2
3
1
2
3
4
REPLACING THE CUTTING BLADE
1. Press the latch on each side of the battery
pack. Remove the battery pack.
2. Turn the nut counterclockwise to loosen
it.
3. Remove the nut, spring washer, and flat
washer.
4. Remove the pivot bolt on the other side of
the cutting blade.
5. Unhook the top of the spring from the
hole on the cutting blade. Unhook the
bottom of the spring from the hole near
the steel wire. Remove the spring.
