Ryobi OLP1832B - Page 16

16
Maintenance
2
1
1
2
11
2
1
3
12
13
14
15
11. Hook the bottom of the spring into the
hole near the steel wire. Hook the top
of the spring into the hole on the cutting
blade.
12. Insert the flat washer, spring washer, and
nut.
13. Using a wrench, turn the nut clockwise
until the spring washer is compressed.
14. Connect the steel wire through the thread
hole of the stamping connector until it
comes in contact with the nut.
15. Insert the gauge between the blades.
Using a wrench, turn the adjustment
screw clockwise to adjust the nut position
to the correct opening size of the blade.
