Page 10
OPERATION
WARNING:
Always wear safety goggles or safety glasses with side
shields during operation.
Fig. 4
Fig. 5
Fig. 6
APPLY POLISH TO SURFACE
See Figure 5.
While holding the polisher firmly against the surface, slide
the ON/OFF switch to the ON position (to the left). Always
start and stop the polisher on or against the surface being
polished.
Begin by polishing larger flat surfaces, such as the hood,
trunk and roof. Use a broad sweeping motion in a criss-
cross pattern. Do not press down on the surface with the
polisher. Let the orbital action of the pad and bonnet do the
work.
Once flat surfaces have been covered, polish curved
surfaces such as car doors and quarter panels. Use small
circular motions. Grip the polisher firmly, allowing the cord
to hang free.
After applying polish to the entire surface, turn polisher off
by pushing the ON/OFF switch to the right. Wait until the
pad stops rotating before lifting the polisher from the
surface. Unplug the polisher.
For hard to reach areas, such as the underside of bumpers
or side mirrors, apply polish by hand.
WARNING:
Do not wear loose clothing or jewelry and contain long
hair when operating buffer/polisher. They could get
caught in moving parts, causing serious injury.
CHANGE TO BUFFING BONNET
See Figure 6.
Remove the application bonnet by loosening the drawstring
and slipping the bonnet off the pad. Replace with buffing
bonnet, attaching it the same way as the application bonnet.
Buff the surface in the same order as it was polished,
starting with large flat surfaces and ending with hard-to-
reach areas. Use the same motion as for polishing, a broad
sweeping criss-cross pattern on large flat areas and small
circular motions on all other areas. Remember to let the tool
do the work.
Note: The part number for one replacement applicator
bonnet and one replacment buffing bonnet is A38RB01.
CAUTION:
To avoid damaging the motor from overheating, do not
let your hand cover the air vents.
