WARNING
If any parts are damaged or missing do not operate
this tool until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
WARNING
Do not attempt to modify this tool or create
accessories not recommended for use with this
tool. Any such alteration or modifi cation is misuse
and could result in a hazardous condition leading to
possible serious personal injury.
NOTE: The chain saw has been fully factory tested. It is
normal to fi nd some slight oil residue on the saw. Read
and remove all hang tags and store with the Operatorʼs
Manual.
See Figure 34-43.
Read the replacing the guide bar and chain section later
in this manual.
SPECIFICATIONS
35 cc 40 cc 44 cc
Weight - No bar, chain, fuel or oil 4.4 kg 4.4 kg 4.4 kg
Fuel tank capacity 310 cm
3
310 cm
3
310 cm
3
Oil tank capacity 210 cm
3
210 cm
3
210 cm
3
Bar lengths 40 cm 46 cm 50 cm
Chain pitch 9.53 mm 9.53 mm 8.26 mm
Chain gauge 1.27 mm 1.27 mm 1.27 mm
Chain type
Low profi le, low kickback Low profi le, low kickback Low profi le, low kickback
Drive sprocket 6-tooth 6-tooth 7-tooth
Engine displacement 35 cm
3
40 cm
3
44 cm
3
Rated power 1.6 kW 1.8 kW 2.0 kW
Rated speed 12000 min
-1
12000 min
-1
12000 min
-1
Idling engine speed 2700 - 3100 min
-1
2700 - 3100 min
-1
2700 - 3100 min
-1
Sound pressure level(ISO22868) 100 dB(A) 100 dB(A) 100 dB(A)
Sound power level (ISO22868) 110 dB(A) 110 dB(A) 110 dB(A)
Vibration (ISO22867)
- Front Handle 4.5 m/s
2
4.5 m/s
2
4.5 m/s
2
- Rear Handle 7.3 m/s
2
7.3 m/s
2
7.3 m/s
2
DESCRIPTION (Fig. 1)
1. Front hand guard / Chain Brake
2. Front handle
3. Cylinder cover
4. Primer bulb
5. Choke knob
6. Clutch cover
7. Bar mounting nuts
8. Guide bar
9. Low kickback saw chain
10. Starter / fan housing
11. Starter grip
12. Ignition switch
13. Trigger release
14. Rear handle
15. Throttle trigger
16. Chain oil cap
17. Fuel cap
ASSEMBLY
