İKLAMA
1. Kafa tertbatı
2. Plaka
3. Taban
4. Raf
5. Sütun tertbatı
6. Raf halkası
7. Besleme kolları
8. Sonsuz dşl
9. Tezgah klt kolu
10. Tezgah krank kolu
11. Altıgen cıvatalar
12. Mandren
13. Sıkma anahtarı
14. 4 mm alyan anahtarı
15. 3 mm alyan anahtarı
16. Düz Tornavda
17. İnglz anahtarı
18. 12 mm anahtar
19. Çekç ya da lastk tokmak
20. Ayarlı gönye
21. Tahta parçası
22. Motor
23. Lazer başı
24. Makara dönüş bobn / yayı
25. Tezgah braket
26. Kasnak kapağı
27. Açma/kapama anahtarı
28. Lazer anahtarı
29. Üst emnyet muhafazası
30. Montaj delğ
31. Kafa kltleme vdası
32. Kayış gergnlğ klt dü
ğmes
33. Sıkma anahtarı tutucu
34. Ml makarası
35. Motor makarası
36. Tezgah desteğ
37. Tezgah krank kolu delğ
38. Sütun desteğ
39. Ayar vdası
40. Kafa
41. Kafa kltleme ayar vdası
42. Dşl delkler
43. Poyra
44. Ml
45. Cıvata x 2 (M12, dahl değldr)
46. Kltl pul x 4 (Da. 12mm, dahl değldr)
47. Lastk pul x 2 (Da. 12mm, dahl değldr)
48. Yassı pul x 2 (Da. 12mm, dahl değldr)
49. Kontra somun x 2 (M12, dahl değldr)
50. Altıgen somun x 2 (M12, dahl değ
ldr)
51. Çalışma yüzey
52. Eğm cetvel
53. Tezgah eğklğ kltleme cıvatası
54. Somun
55. Kontra somun
56. Vdalar
57. Alt ön anahtar dş
58. Yay başlığı
59. Dış kontra somun
60. İç somun
61. Çentk
62. Topuz
63. Mandren çeneler
64. Matkap ucu
65. Dernlk
66. Dernlk ölçeğ gösterges
67. Dernlk cetvel
68. Üst somun
69. Alt somun
70. Dernlk tespt mandalı
71. Üzernde çalışılacak malzeme
