Ryobi RPP254FEJSN - Product Specifications

6
English
39. Bar nut
40. Drivecase cover
FIGURE 16
39. Bar nut
40. Drivecase cover
FIGURE 17
41. Bar stud
42. Sprocket
43. Bar stud slot
44. Chain tensioning pin hole
FIGURE 18
2. Chain
39. Bar nut
42. Sprocket
44. Chain tensioning pin hole
45. Chain rotation
FIGURE 19
46. Chain tensioning screw
FIGURE 20
39. Bar nut
FIGURE 21
47. Idle speed screw
FIGURE 22
48. Chain bar oil reservoir
49. Remove cap
50. Replace cap
FIGURE 24
51. Top plate
52. Rivet hole
53. Heel
54. Gullet
55. Toe
52. Rivet hole
56. Depth gauge
57. Side plate
58. Cutting corner
FIGURE 27
59. Left hand cutters
60. Right hand cutters
FIGURE 28
61. Foam air lter
62. Air lter cover
63. Cover securing knob
FIGURE 30
64. Spark plug boot
65. Spark plug
FEATURES
PRODUCT SPECIFICATIONS
Engine displacement 25.4 cc
Weight 7.1 kg
Pruner reach without extension 1850 mm (73 in)
Pruner reach with extension 2745 mm (108 in)
Fuel tank volume 620cm
3
Maximum engine performance (in
accordance with ISO 8893)
0.9kW
Engine speed (rotational
frequency) at recommended max.
spindle rotational frequency
12000 min
-1
Engine speed (rotational
frequency) at idle
2600-3200 min
-1
Fuel consumption (in accordance
with ISO 8893) at max. engine
performance
0.54 kg/h
Specific fuel consumption (in
accordance with ISO 8893) at max.
engine performance
0.50 kg/h
Vibration (in accordance with ISO 22867)
Front handle
- Idle 3.8 m/s
2
- Racing 2.4 m/s
2
- Equivalent vibration total value 3.1 m/s
2
Read handle
- Idle 3.8 m/s
2
- Racing 7.9 m/s
2
- Equivalent vibration total value 5.9 m/s
2
Uncertainty 1.5 m/s
2
Noise emission (in accordance with ISO 22868)
