8
WARNING
While operating and storing, keep at least 1m (3 feet)
of clearance on all sides of this product, including
overhead. Allow a minimum of 30 minutes of “cool
down” time before storage. Heat created by mufer and
exhaust gases may be hot enough to cause serious
burns and/or ignite combustible objects.
USING THE SPRAY WAND TRIGGER
See gure 13.
■ Pull back and hold the trigger to operate the pressure
washer.
■ Release the trigger to stop the flow of water through
the nozzle.
To engage the lock out:
■ Push up on the lock out until it clicks into the slot.
To disengage the lock out:
■ Push the lock out down and into its original position.
For the most effective cleaning, the spray nozzle should be
between 200 mm (8 in.) and 600 (24 in.) from the surface
to be cleaned. If the spray is too close it can damage the
cleaning surface.
INSTALLING/REMOVING NOZZLES
See gure 14.
WARNING
Never change nozzles or spray patterns without locking
the lock out on the trigger handle and never point the
wand at your face or at others. The quick-connect
feature contains small springs that could eject the
nozzle with some force. Failure to heed this warning
could cause personal injury.
Using the quick-connect collar, changing the nozzle is
easy.
To connect the nozzle to the trigger handle:
■ Turn off the pressure washer and shut off the water
supply. Pull trigger to release water pressure.
■ Engage the lock out on the trigger handle by pushing
up on the lock out until it clicks into the slot.
■ Push the nozzle into the quick-connect collar until it
clicks in place and is secured properly.
To disconnect a nozzle from the trigger handle once
the cleaning job is complete:
■ Turn off the pressure washer and shut off the water
supply. Pull trigger to release water pressure.
■ Engage the lock out on the trigger handle by pushing
up on the lock out until it clicks into the slot.
■ Remove the nozzle by placing hand over nozzle then
pulling back the quick-connect collar.
USING THE 5-IN-1 CHANGE OVER NOZZLE
See gure 15 .
There are ve spray pattern settings located on the 5-in-1
Change Over Nozzle. To select a spray pattern, rotate the
spray selector to the desired setting.
Nozzle Application
0
o
Spot cleaning of high, hard-to-reach areas
● Removing caked-on mud from heavy
construction, farm, or lawn equipment
● Cleaning tar, glue, or stubborn stains
from concrete
● Cleaning overhead areas
● Removing rust from steel and oxidation
from aluminum
25
o
For general purpose or large surfaces
• General cleaning of dirt, mud, and grime
• Cleaning roofs, gutters, and downspouts
• Removing light mildew stains
• Removing algae and bacteria build-up
from pools
• Rinsing surfaces in preparation for
painting
40
o
For wide-angle rinsing
● Light cleaning and washing
● Washing and rinsing of painted
surfaces and boats
● Cleaning roofs, windows, patios, and
driveways
Soap short range For short range detergent applications
• Driveways, walkways, decks and patios,
vehicles, fences, paint prep, patio
furniture, and lawn equipment
Soap long range For long range detergent applications
• Second story washing
USING THE HIGH PRESSURE HOSE
The high pressure hose features an outer covering
that provides strength to the hose. If the outer covering
becomes damaged, the hose must be replaced
immediately. Do not use a high pressure hose if the
outer covering is damaged.
To prevent damage to the outer covering:
■ Inspect the hose before every use.
■ Fully unwrap and straighten hose before use.
■ Do not allow the high pressure hose to be kinked.
■ Keep hose away from hot surfaces and sharp edges.
■ Do not pull unit by high pressure hose.
■ Do not allow hose to be crushed or wrapped around
objects.
