Ryobi RPW3200 Operator's Manual

DESCRIPTION
1. 5-in-1 Change Over Nozzle
2. Detergent tank
3. Spray wand
4. Fuel valve
5. On/off switch
6. Choke lever
7. Fuel cap
8. Trigger with lock out
9. Trigger handle
10. High pressure hose
11. High pressure hose storage
12. Air lter cover
13. Fuel tank
14. Handle
15. Starter grip with rope
16. Mufer
17. Handle release knob
18. Screw (1/4-20 x 2.0 in., T30 Torx head)
14
9
10
3
4
9
8
7
5
6
1
13
15
16
2
11
17
18
19
20
22
20
21
14
24
Fig.2 Fig.3
Fig.1
19. Hose storage
20. Hex nut
21. Washer
22. Trigger handle holder
23. Spray wand holder
24. Screw (1/4-20 x 1.77 in., T30 Torx
head)
25. Connector
26. Inlet coupler
27. Collar
28. Garden hose
29. Water intake coupling
30. Filter
31. Air lter knob
32. 0.75mm (0.030 in.) plug gap
33. Oil lter hole
34. Air lter
35. Oil cap/dipstick
36. Upper ll level
37. Funnel
38. Recoil starter
39. Choke Start position
40. Choke Run position
41. Fuel switch off position
42. Fuel switch on position
43. Engine switch on position
44. Engine switch off position
45. Lock out
46. Slot
47. Quick-connect collar
48. Spray selector
49. Soap Long Range
50. Soap Short Range
51. Container
52. Paper clip

Ryobi RPW3200 Specifications

General

Brand	Ryobi
Model	RPW3200
Category	Pressure Washer
Language	English
