Ryobi RPW3200 User Manual

8
PACKING LIST
See page 16.
■ High pressure cleaner
■ 7.6 m (25 ft.) high-pressure hose
■ Trigger handle holder
■ Spray wand holder
■ Trigger handle
■ Spray wand
■ Screw (1/4-20 x 2.0 in., T30 Torx head)
■ Flat washer
■ 2 x Screw (1/4-20 x 1.77 in., T30 Torx
head)
■ 3 x Hex nut (1/4-20 in.)
■ 5-in-1 change-over nozzle
■ 4-cycle engine lubricant (SAE 30 or SAE
10W30)
■ Hose storage
■ Operator’s manual
TOOLS NEEDED
The following tools are not included in the
package but are needed for the assembly:
■ 7/16 in. wrench
■ T30 head screwdriver
WARNING
If any part is damaged or missing, do not
operate the product until the part is replaced.
Using the product with damaged or missing
parts could result in serious personal injury.
WARNING
Do not attempt to modify the product or
create accessories not recommended for
use with the product. Such alteration or
modication is a misuse and could result in
a hazardous condition leading to possible
serious personal injury.
WARNING
To prevent accidental starting that could
cause serious personal injury, always
disconnect the engine spark plug wire from
the spark plug when assembling parts.
RAISING AND LOWERING THE HANDLE
See page 18 (step 2).
■ To raise the handle (for moving the high
pressure cleaner), pull the handle up until
the handle release knob snaps into locking
position. Ensure the lock is secured in the
frame hole before moving the product.
■ To lower the handle (for storing or
transporting the high pressure cleaner),
pull the handle release knob out and lower
the handle to the down position.
NOTE: The handle cannot be locked in the
down position.
Never use the handle to lift the high pressure
cleaner. The handle should only be used for
moving the product by rolling it on its wheels.
INSTALLING HOSE STORAGE, TRIGGER
HANDLE HOLDER, AND SPRAY WAND
HOLDER
See page 19 (steps 3 to 4).
■ Raise the handle as described in the
Raising and Lowering Handle section.
■ Place hose storage onto the handle as
shown.
■ Align the holes in the hose storage with the
holes in the handle.
■ Insert screw (1/4-20 x 1.77 in.) through the
holes in the left side of the handle and hose
storage.
■ Place the nut onto the bolt and tighten.
■ Place the trigger handle holder onto the
handle as shown.
■ Align the holes in the trigger handle holder
with the holes in the hose storage and the
handle.
■ Insert the screw (1/4-20 x 2.0 in.) through
the holes in handle, hose storage, and
trigger handle holder.
■ Turn bolt while holding the nut in place to
tighten and secure.
■ Place spray wand holder onto high
pressure cleaner frame.
■ Align the holes in the spray wand holder
with the holes in the high pressure cleaner
frame.
■ Insert screw (1/4-20 x 1.77 in.) through the
holes in the spray wand holder and the
high pressure cleaner frame.
■ Place nut onto screw and tighten.
