RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS16
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST
* Standard Hardware Item – May Be Purchased Locally
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 410101005 * SCREW (M5 x 15 mm) ..............................................................2
2 089110109001 THROAT PLATE .........................................................................1
3 0121011301 THROAT PLATE ADJUSTING PAD ............................................2
4 410151713 * SCREW (1/4-20 x 46 mm HEX HD.) ..........................................1
5 089110109002 SAW TABLE ...............................................................................1
6 089110109908 SCALE LABEL ...........................................................................1
7 0131010221 HANDLE BRACKET ...................................................................1
8 410171722 * SCREW (10-24 x 3/8 in.) ...........................................................2
9 0121010318-129 RIGHT SCALE INDICATOR .......................................................1
10 0121010319-129 LEFT SCALE INDICATOR ..........................................................1
11 410192001 * SCREW (M4 x 10 mm) ..............................................................8
12 411071003 NYLON NUT (M5) ......................................................................4
13 0121010214 SHORT BRACKET .....................................................................4
14 410171706 SCREW (10-24 x 1/2 in.) ...........................................................8
15 0121010903 AUXILARY TABLE CLAMPING HANDLE SCREW .....................4
16 414011033 SPRING PIN (D5 x 18 mm) ........................................................4
17 0121010211 TABLE LOCKING LEVER ...........................................................4
18 0121010215 OUTFEED ROD PRIMARY BRACKET .......................................2
19 A121014301 MOTOR BRACKET ASSEMBLY ................................................1
20 0121010314 ADJUSTING PLATE ...................................................................1
21 410371002 * SCREW (M6 x 15 mm HEX w/WASHER) ..................................2
22 0121010901 ECCENTRIC ROLLER ...............................................................1
23 0121010313 PIVOT BRACKET PLATE ...........................................................2
24 410341006 * SCREW (M6 x 12 mm HEX WITH WASHER) ............................4
25 089110109707 MOTOR ASSEMBLY..................................................................1
26 0121010902 GLIDER......................................................................................1
27 410161001 * SCREW (M6 x 15 mm HEX - TOOTH HD.) ................................3
28 0131010912 BLADE NUT (5/8-18NF-2B) .......................................................1
29 0101010302 OUTER BLADE WASHER ..........................................................1
30 089110109030 BLADE .......................................................................................1
31 0121010502 INNNER BLADE WASHER ........................................................1
32 0121010501 SPACER ....................................................................................1
33 412011701 WASHER (1/4 in. x 16 x 1t) .......................................................2
34 0121010321 FRONT GUARD ........................................................................1
35 410251018 BOLT (M6 x 8 mm) ....................................................................2
36 412042702 WASHER (1/4 in.) ......................................................................1
37 410079021 * SCREW (M5 x 6 mm SOC.) .......................................................1
38 0121010802 WING SCREW (M6 x 16 mm) ....................................................1
39 0121010105 BLOCK ......................................................................................1
40 410602002 * SCREW (M4 x 25 mm) ..............................................................2
41 0121010236 LEFT END PLUG .......................................................................1
42 0121010237 RIGHT END PLUG .....................................................................1
43 0121010317 DADO THROAT PLATE (NOT SHOWN) .....................................1
