Page 3 of 3 RTS20 12-10-10
Fig 3: Bevel lock lever with new pad
Note: when replacing the above parts, it is also recommended to replace the nut
(part 089037008039) at the end of the bevel lock lever screw shown in Fig 1.
Submit warranty claim using………………………RTS20 12-10-10
Warranty claim compensation……………………...Use Ryobi Labor Chart
For Technical assistance contact Ryobi Technical Support at 1-800-525-2579
