21
ASSEMBLY
MITER
GAUGE
BLADE
WRENCHES
STORAGE
HOOK
TO STORE THE TABLE SAW ACCESSORIES
See Figures 20 - 21.
The table saw has two convenient storage areas (one on
either side of the saw cabinet) specifically designed for the
saw’s accessories.
When not in use, store the accessories securely by snapping
each accessory in place.
Fig. 21
RIP
FENCE
Fig. 20
PUSH
STICK
Fig. 19
DUST
BAG
DUST
CHUTE
ELBOW
TO INSTALL DUST BAG
See Figure 19.
Slide the elbow inside the dust chute on the back of the
table saw.
NOTE: For efficient operation, empty the dust bag before it
is half full. This will permit better air flow through the bag.
