Page 10 — English
KNOW YOUR GENERATOR
See Figure 2.
The safe use of this product requires an understanding of the
information on the product and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
AC CIRCUIT BREAKERS
The circuit breakers are provided to protect the generator
against electrical overload. The circuit breaker may be reset
by pressing the circuit breaker reset button.
AIR FILTER
The air filter helps to limit the amount of dirt and dust drawn
into the unit during operation.
ANSI/UL-2201 CERTIFIED
This generator complies with the ANSI/UL-2201 Standard
for Low Carbon Monoxide (CO) Emission Rates for portable
generators. When used properly, portable generators with
lowered CO emissions and CO shutoff capability mitigate
the risk of CO related poisoning.
DANGER:
ANSI/UL 2201 compliance is not a substitute for safe
generator practices. Always operate the generator in
open, outdoor areas, at least 20 feet away from occu-
pied structures. Never operate the generator near open
windows, doors, or other unventilated spaces.
CHOKE LEVER/FUEL VALVE
The choke lever/fuel valve is used when starting, stopping,
and running the engine.
DIGITAL DISPLAY
The digital display shows AC voltage output, frequency, how
long the engine has been running during the current usage
period, and the total number of hours the unit has been used.
ENGINE STOP SWITCH
To turn the engine off, turn the engine stop switch to the
OFF position.
FUEL TANK
The fuel tank has a capacity of 6 gallons.
GROUND TERMINAL
The ground terminal is used to assist in properly grounding
the generator to help protect against electrical shock. Consult
with a qualified local electrician for grounding requirements
in your area.
LOW OIL SHUT DOWN PROTECTOR
The low oil sensor causes the engine to stop if the level of
lubricant in the crankcase is insufficient.
OIL CAP/DIPSTICK
Remove the oil fill cap to check and add lubricant to the
generator when necessary.
OIL DRAIN PLUG
When changing the engine lubricant, unscrew and remove
the oil drain plug to allow old engine lubricant to be drained.
RECEPTACLES
Your generator has the following single phase, 60 Hz outlets:
two 120 Volt AC duplex 20 Amp GFCI protected receptacles,
and one 240 Volt AC, 30 Amp receptacle. These can be used
for operating appropriate appliances, electrical lighting, tools,
and motor loads.
RECOIL STARTER GRIP
The recoil starter grip is used to start the generator’s engine.
PRODUCT SPECIFICATIONS
ENGINE
Engine Type
......................................................420cc, OHV
Replacement Spark Plug
.............. LG F7RTC or equivalent
Lubricant Fill Volume
......................... approximately 32 oz.
Fuel Volume
................................................................ 6 gal.
GENERATOR
Rated Voltage
.................................................... 120V/240V
Rated Amps ..................................................... 58.3A/29.1A
Rated Output* ..........................................................6800 W
Starting Watts .......................................................... 8500 W
Rated Frequency ........................................................60 Hz
FEATURES
*Rated output determined by PGMA Standard G300
