ACTION RESPONSE
1. Set Battery Master Switch to ON
position.
------
2. Set Avionics Master Switch to ON
position.
------
3. Set Autopilot Master Switch to ON
position.
HDG lamp is illuminated and GPSS
lamp is extinguished on HDG / GPSS
Selector Switch, as an indication that
GPSS Converter’s HDG mode is
engaged. This is shown in Fig. 2-1a.
4. Set Heading Bug under Lubber
Line.
------
5. Engage autopilot’s HDG mode. ------
6. Turn Heading Bug to the left side
of Lubber Line.
A/C Control Wheel turns to the left.
7. Turn Heading Bug to the right
side of Lubber Line.
A/C Control Wheel turns to the right.
8. Set Heading Bug under Lubber
Line.
A/C Control Wheel stops.
9. Program GPS Navigator with a
valid waypoint.
------
2.1 Pre-Flight Test
Prior to takeoff and with engine running, perform the actions shown in Table 2-1.
For each action, verify the corresponding response where applicable.
Table 2-1. Pre-Flight Test (continued on page 2-4)
