Fi g. 20
Before inserting pulley, stick disc
(3, Fig. 19) 0.8 mm thick (0.032 in.)
with a little grease into recess of
pulley.
Fit pulley on to bearing bolt and
insert end of spring (4, Fig . 19)
at stud (1 ).
Tension pulley/coil sp ring in di-
rection
of cord exit until stop is
encountered .
Release coil spring
approx.
1
h ... 1
turn until the recess
for the sol-
dering nipple
in the pulley rests
near the cord duct of the hous-
ing.
Again hold
the pulley firmly with
home-
made retaining clip (1,
Fig. 21 ).
Pull the starter cord through a
rag soaked with SAE-1 0 oil be-
fore assembling.
Fig. 21
Note:
When converting starting direc-
tion, reposition cord
guide (2)
also.
Fit starter handle with stop and
clamping ring on to cord.
Lay
starter cord around clamp-
ing
tap er and pull it into clamp-
ing ring.
Pull clamping ring into s tart er
handle and let starter cord run
back.
Fig. 22
Screw labyrinth ring (2) tight.
Lubricate
starter pawl bed and
starter pa wls lightly with SAE -1 0
oil.
Fit s tart er pawls (1 and 4).
Th e OJJen side of the starte 'r pa wl
seoti f;l g and the long side of the
starter pawl face in starting di-
rection.
Fit washer 0.1 mm (0.0039 in .)
thick, friction
plat e (3), spring
ring
and s him s as required.
In sert brake spring (5).
F &Sl..071:37
Fig. 20
F & 5 407 1:31..
Fi g. 21
F &St..071 :33
Fig. 22
('\ ..
After mounting the br ake spring, the friction pla Je sho ul d h ave a n ax ia l pl ay of
0.1 ... 0.2 mm (0.0039 ... 0.0079 in.). . ,
Correct this play by putting shims under the
brake S!"ring.
15
