10/11
7.10 Grinder adjustment during servicing
Loosen the screw on the coffee
container.
To vary the grinding setting,
tighten or loosen with wrench “A”
supplied.
(+) = Coarse grinding
( - ) = Fine grinding.
WARNING:
- Grinding must be adjusted with the motor in movement.
- Adjust the grinding level by one step at a time.
- After setting grinding, run two grinding cycles and check the resulting gran-
ules and dose.
- Repeat if further adjustment is required.
TALEA Section 07
REV00 - August 06
+
-
A
To adjust the coffee grinder (in addition to user-permitted adjustments of “C” with the grinding
adjustment tool “A”), remove the coffee granule container and turn adjustment insert “B” to
widen or tighten grinding. This insert can be repositioned to move interval “C”.
Be very careful not to separate the grinders from their supports.
C
B
