INTEGRA/-S/-G/-GS User Manual WEB GUI
SAF Tehnika JSC
The default frequency range (indicated on the label) is defined for 3.5MHz channel
bandwidth.
Allows filtering the bandwidth selection list by FCC or ETSI standard and with or without
AES encryption enabled, as well as selecting “All” to disable filtering.
If allowed by the license, AES-encrypted bandwidth options will be available. Please refer to
the Over the Air→Security→AES encryption chapter for further details and activation steps of
AES encryption.
Allows choosing between available channel bandwidth options along with the indication of
fixed modulation or maximum modulation for ACM, bandwidth standard ETSI or FCC, AES
encryption functionality, and Tx power mode – fixed or variable – in case ACM profile is
chosen.
Please refer to the Over the Air→Security→AES encryption chapter for further details and
activation steps of AES encryption.
Allows choosing between available modulations for the selected channel bandwidth.
The “FEC” suffix indicates a better sensitivity mode (longer FEC overhead), while “Weak
FEC” indicates a higher capacity mode (shorter FEC overhead).
“Weak FEC” is available only for the highest modulation for the selected channel bandwidth.
ACM stands for Adaptive Coding and Modulation and enables the adaptive modulation
change according to MSE value. Modulation indicates maximum modulation, while the
minimum is 4QAM.
Allows enabling/disabling each of three available LAN ports.
In case 2+0 aggregation is enabled, the LAN2 state is “Restricted” as it can be used only for
interconnection between two Integra/Integra-S/Integra-G/Integra-GS FODUs. Please refer to
the Over The Air → Modem → Aggregation configuration chapter for further details.
By pressing „Execute configuration”, changes made to the corresponding section apply only
to the local side Integra/Integra-S/Integra-G/Integra-GS. If „Rollback on” is selected, the
configuration will be reverted in case erroneous configuration changes are applied.
Rollback triggers when configuration changes applied interrupt management connectivity.
For this reason, rollback will not work if the remote side of the link is not reachable.
Pressing „Execute for both” applies changes made to the corresponding section both for
local and remote side Integra/Integra-S/Integra-G/Integra-GS FODUs.
