PR9 SERVICE MANUAL
-
VER1.1
Page
111
of
112
7.2. PR9 COMMUNICATION CABLE CONNECTION TABLE
1. 9 PINS----- 9PINS<PR-9T9>
2. 25PINS-----25PINS<PR-PRINT>
7.2.1. PR-9T9 COMMUNICATION CABLE TABLE
Application Area : Host with standard 9 pins of RS232 serial port and PR9
communication cable.
HOST: 9 PINS (DB-9S) PRINTER: 9 PINS (DB-9S)
1
2
3
4
5
6
7
8
9
1
3
2
6
5
4
8
7
9
RXD
DCD
TXD
DTR
GND
DSR
RTS
CTS
DCD
TXD
RXD
DSR
GND
DTR
CTS
RTS
METAL
SHELL
METAL
SHELL
SHIELDING
LAYER
7.2.2. THE PARALLEL COMMUNICATION CABLE TABLE OF
PR9 CONNECT TO THE HOST
Application Area: host with standard Centronics IEEE parallel interface and
PR9 communication cable.
