3029
Locate Rear-Facing Belt Path
Route the Vehicle Belt
Thread the vehicle belt into the Rear-
Facing Belt Path opening.
Pull it across the seat, under the seat
pad, in front of the buckle, and out
through the other belt path opening.
Do not twist belt.
Check Rear-Facing Level
Lines
For children between 5-22 lb
(2.3-10 kg), the bottom level line on
shell must be parallel with the ground.
For children 22-40 lb (10-18 kg)
who can sit up unassisted, rotate
the child restraint between the 2 level
lines.
Start by making the bottom level line
parallel with the ground, then rotate
seat up. Do not rotate past the top
level line.
Check if Your Vehicle Belts
Will Work With This Child
Restraint
This is very important because not
all vehicle belts will work with child
restraints.
Review pages 21-24 and your vehicle
owner’s manual to determine what
kind of vehicle belt you have and how
to lock a child restraint in place.
3
4
5
6
Place Car Seat Rear-Facing
in Back Seat
2
To Next Page
