Changing Harness Height
and Headrest Height
10
Forward-Facing Child Fit
9
Need to make adjustments?
To change headrest/harness height, see pages 10-12.
To change buckle position, see pages 13-14.
Harness Strap Position
The harness strap must be at or
slightly above the shoulders;
never below.
Buckle Position
Buckle can be used in any slot. Choose
the slot closest to your child.
The buckle should not be
underneath or behind your child.
Head Position
The tops of your child’s ears
must be below the top of the
car seat’s headrest.
1
2
3
Max Seated Shoulder Height
In this car seat, the maximum seated
shoulder height is 16.5 in. (42 cm).
To measure your child’s seated
shoulder height: have them sit on the
fl oor with their back fl at against a wall.
Then measure from the fl oor up to the
top of their shoulder.
Max Seated
Height
16.5 in
(42 cm)
Fully Loosen Harness
Straps
Push down on harness release
lever (through opening in pad) while
pulling out on harness straps as
shown.
From Back of Seat,
Remove Harness Strap
Loops From Splitter Plate
Pull Harness Strap Out
of Shoulder Harness Slots
1
2
3
Rethread Harness Strap
Into Correct Shoulder
Harness Slots For Your
Child
4
For Rear-Facing child fi t,
see page 8.
For Forward-Facing child fi t,
see page 9.
