Safety 1st Guide 65 - Page 32

57 58
sewn
end
9
10
Attach 1st Harness Strap
Loops to Splitter Plate As
Shown
Sewn ends of the harness strap
loops must face towards you. Do
not twist harness strap or harness
adjustment strap.
Make sure the same harness strap
loops are fitted completely on both
sides of the splitter plate.
Harness strap loop ends must go
through the recline stand as shown.
Harness adjustment strap must lie
under the harness strap as shown.
8
7
From the Back,
Pull Harness Strap
Through Pad and Shell
Harness strap must be under the
headrest adjustment bar as shown.
Do not twist harness strap.
Thread Buckle and
Chest Clip
Harness strap ends go through the
back of buckle tongues and through
the chest clip front to back as
shown.
Thread Harness Straps
into Correct Shoulder
Harness Slots for Your Child
Harness strap must be under the
headrest adjustment bar as shown.
Do not twist harness strap.
For Rear-Facing child fi t, see page 8.
For Forward-Facing child fi t, see page 9.
WARNINGS: The harness system must be installed
correctly. Do not use a child restraint with damaged
harness straps.
Recline Stand
Harness Adjustment
Strap
Check your child’s fit often.
If you cannot achieve a snug harness fit for your child,
see pages 15-17.
To learn how to check harness tightness, see pages 48-50.
Check the harness straps often for any wear or damage.
