Safety Vision SV-LED70WQ4 User Manual

Name: Safety Vision SV-LED70WQ4
Brand: Safety Vision
Rating: 4 (1 reviews)

12 pages

To Next Page

To Previous Page

AUDIO INPUT

+12V DC OUTPUT,

HEATER & SHUTTER

+12V DC OUTPUT,

POWER

VIDEO INPUT

GROUND

CAMERA INPUT

CONNECTION

CAM 1

Ground(Black)

Trigger 1(Green)

Trigger 2(White)

Trigger 3(Blue)

Trigger 4 or Tacho(Yellow)

Audio In(White)

Video In(Yellow)

Main power 12V/30V DC(Red)

CAM 2

CAM 3

CAM 4
