Safeway MARLIN - Removing the 5-point harness

12
Removing the 5-point harness
1 - Loosen the shoulder straps (See page 8).
2 - Remove the comfort pad (Fig.1).
3 - At the back of the seat, remove the Harness Protector Cover by removing
the 3 screws holding it to the shell (Fig.2).
4 - Remove the Shoulder Straps from the Harness Yoke then pull the shoulder
straps forwards through the shell and cover (Fig.3).
5 - Remove the Shoulder Pad straps from the metal shaft by moving the
headrest to it’s highest position then pull the shaft outwards to the side and
remove the belts (Fig.4).
6 - Adjust the child seat to the fully reclined position (Fig.5).
7 - Remove the crotch strap from underneath the seat by twisting the metal
buckle sideways and pushing it upwards through the shell and cover (Fig.6).
8 - Remove the harness system from the seat.
IMPORTANT: Store the harness system, crotch pad and shoulder pads in
a safe place for future use.
Fig.1
Fig.2 Fig.3
Fig.4
Fig.5
Fig.6
