14
Install Forward Facing - Group 2 / 3 (15 to 36kg) - Seat Belt Install
First remove the Harness System (see Page 12).
1 - Adjust the recline position by pulling the red handle at the front of the seat
and adjust the seat to Position 1 (Fig.1).
2 - Thread the diagonal belt through the Diagonal Belt Guide (Fig.2).
3 - Place your child in the seat (Fig.3).
4 - Fasten the belt around your child. Clip the seat belt tongue into the buckle
and remove any slack on the shoulder belt by pulling it lightly upwards (Fig.4).
Fig.1
Fig.2
Fig.3
Fig.4
To Next Page
