32
Appendix A: Part number reference
Appendix B: Glossary
# Saft P/N Description
3. 771285 Fuse, replaceable, 60 A
4. 771473IO Installation and operation instructions
5. 771492 -xx
Evolion module, -xx is the parameter file variant.
-09 RS_speed = 1
-10 RS_speed = 0
-11 Standard
-12 Alarm #35 and #36 output to dry contact
6. 772309 Communication kit, USB key and converter cable
7. 772509 Evolion packaging box, UN3480
8. 772517 Cable NEG, 1000 mm, black cable, black heat shrink
9. 772518 Communication cable, inter module
10. 773455 RJ45 Resistor cap
11. 773456 Converter cable
12. 774884 Busbar kit, 4x Evolion, 1 meter communication cable to application
13. 780680 Cable POS, 1000 mm, black cable, red heat shrink
Term Definition
BMST Battery Management System Telecom
BMU Battery Management Unit (not used with Evolion)
DoD % Depth of Discharge
Dry contactor open or close signal, no voltage or current supplied, free contact
EOL End of Life
HMI Human Machine Interface
IMD Maximum Discharge Current
IMR Maximum Re-charge Current
LVD Low Voltage Disconnect
MBMM Master Battery Management Module (not used with Evolion)
OCV Open Circuit Voltage
PFC Potential Free Contact, referred to as dry contact sometimes
SEI Solid Electrolyte Interface or the passivation layer on the negative electrode
SMPS Switch Mode Power Supply
SMU Safety Monitoring Unit (not used with Evolion)
SoC % State of Charge
SOC State of Charge
SOH State of Health
