CV10
Quick Start Guide
SEPTEMBER 2004 6
CV10 PARAMETER GROUPS
Each parameter group branches off into individual parameters. See pages 41 through 50 for more
detailed information about each parameter number.
Parameter
Group No.
Description
0- Drive Operation Mode
1- Start/Stop and Frequency Control Modes
2- Manual/Automatic Restart Modes
3- Operating Parameters
4- Digital Display Operation Mode
5- Multifunction Input Terminals (MFIT)
6- Jog, and Preset (MFIT) Speed Setting on Keypad
7- Analog Input Signal Operation
8- Multifunction Output Relays and Output Signal Operation
9- Drive and Load Protection Modes
10- Volts/Hz Pattern Operation Mode
11- PID Operation Mode
12- PID "Limits" and "Out of Range" Mode
13- Communication Mode
14- Motor Auto-Tuning Parameters
15- Drive Status and Function Reset
To change Parameter Data:
1) Press the key until the display reads "X - YY" (X parameter group, Y parameter
number). The initial value will be "0-00”.
2) Press the or keys to change the parameter number. The first digit to be
changed will always be the farthest to the right “X-YY” and it will be flashing.
3) Press the key to move to the next flashing digit to be changed “X-YY”. Edit by using
the or keys.
4) Press the key to edit the parameter value.
5) Press the or keys to change the parameter value. The digit to be edited will
be flashing.
