SAILFISH 276 DC | TYPE III MSD WASTE MANAGEMENT SYSTEM
Installation:
The holding tank should be located close to the toilet.
A proper seacock is required if the discharge thru-hull is
positioned below the waterline.
Both the discharge thru-hull and the holding tank are
installed to prevent a potential siphon. Contact a marine
plumber or Jabsco technical support specialist for installa-
tion assistance.
Mount on a strong flat surface. Note: the area of installation
needs to support the weight of the unit and its contents.
Four mounting feet (included) need to be attached to the
platform with four machine or lag screws and four flat wash-
ers.
Plumbing:
Each tank contains:
• 1 x 1 ½” deck pump out – evacuation pickup tube (Install
to dockside pump-out deck plate)
• 1 X 1 ½” inlet port – from toilet system
• 1 x 3” O-ring sealed inspiration hatch
• 1 x 1” vent* - connect to vent outlet usually sited high on a
vessel’s hull near the gunwale
• 1 x 1” Overboard discharge port macerator pump out.
Discharge: connect to the overboard discharge thru-hull
fitting.
* See plumbing diagram for recommended installation.
Maintenance:
Flush system with clean water to remove any build up of
sludge or debris. It is recommended that this process be
completed at least once a year. Please reference 18590
Series Macerator datasheet servicing section for details.
Winter Storage:
Empty the complete system of all water making sure pipe
work and pump are completely free of waste.
54
