Sailor A1 VHF-DSC User Manual

4
Installation
RT4800/01
2 Installation
Mounting possibilities, dimensions and drilling plan.
2.1 Mounting Possibilities
Transceiver Unit
The transceiver unit is available in both a one- and a two-aerial version.
A one-aerial DSC transceiver can be converted into a two-aerial version (contact your dealer).
The drawing below shows a two-aerial transceiver unit:
35342
222.00
136.00
100.00
56.50
198.00
242.00
77.50 14.50
4 x ø4.00
OPTION SPARC-BUS
Weight:
Transceiver Unit 1.3 kg
WARNING:
Only use original screws; otherwise you risk short-circuiting the battery ground to the ship ground.
