Sailor A1 VHF-DSC User Manual

7
Installation
RT4800/01
2.4 Options Connector Box H4992
Options connectors
35350
NMEA_IN+
NMEA_IN-
-BAT
+12VDC
FAN_ON
RX_1_SQ
CH_AUX_1
CH_AUX_2
RX_1_AF
NMEA_OUT+
NMEA_OUT-
DSC_ALARM_ON
X1
14
15
13121110
X2
9876
54
1
32
To connect a GPS to the VHF transceiver, connect
the GPS signal lines to the options connector
pin_4 (NMEA_IN+) and
pin_5 (NMEA_IN-).
35379B
GPS H4992
X2
56.111
Alternatively the GPS can be connected directly
to the transceiver by means of a 15-pole high
density D-sub in the same pins as those
mentioned above.
Make sure to use the 15 to 15-pole adaptor
between the transceiver and the 15-pole high
density D-sub.
The two parts (part no. 78.775) are supplied
with the radio.
9915
Transceiver unit Twisted Option box
X2 Name pair X1,X2
pin 1 DSC_ALARM_ON 1
pin 2 NMEA_OUT+1 1 Optional
pin 3 NMEA_OUT-1 1 Optional
pin 4 NMEA_IN+ 2 4
pin 5 NMEA_IN- 2 5
pin 6 -BAT_0VDC 3 6
pin 7 +12VDC 3 7
pin 8 FAN_ON 8
pin 9 RX_1_SQ 9
pin 10 CH_AUX_1 10
pin 11 CH_AUX_1 11
pin 12 RX_1_AF 12
pin 13 N.C. 13
pin 14 N.C. 14
pin 15 N.C. 15
