14 BATTERY PANEL

DISASSEMBLE FOR JUMPER SETTING

1. Remove the 4 crosshead screws from the rear cover.

2. Remover the 4 screws of the two D-sub connectors.

3. Carefully seperate the rear cover from the front.

4. Disconnect the 4 ribboncables from the PCB inside the rear cover.

5. Remover the 5 screws holding the PCB and take out the PCB.

6. Re-connect the 4 ribboncables to the PCB.

7. Perform the jumper settings as described on the next page.

8. Re-assemble the Battery Panel.

INSTALLATION
