6 PARTSLIST RT2047 DSC - PART II
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
PAGE 5-8
9810
C25-6 CAPACITOR MKT 220nF 5% 63VDC PHILIPS 2222 370 79224 11.182
C26-6 CAPACITOR POLYSTYRENE 15nF 1% 160V #PHILIPS 2222 429 81503 10.304
C27-6 CAPACITOR ELECTROLYTIC 100uF -10/+50% 25VDC ERO EKM 00 CC 310 E G5 14.610
C28-6 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ERO EKI 00 AA 210 F M5K 14.512
C29-6 CAPACITOR POLYSTYRENE 8,2nF 1% 160V #PHILIPS 2222 429 88202 10.298
C30-6 CAPACITOR POLYSTYRENE 8,2nF 1% 160V #PHILIPS 2222 429 88202 10.298
C31-6 CAPACITOR POLYSTYRENE 15nF 1% 160V #PHILIPS 2222 429 81503 10.304
C32-6 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C33-6 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C34-6 CAPACITOR POLYSTYRENE 1n00F 1% 250VDC PHILIPS 2222 430 81002 10.350
C35-6 CAPACITOR POLYSTYRENE 220pF 1% 630VDC PHILIPS 2222 431 82201 10.409
C36-6 CAPACITOR POLYSTYRENE 1n00F 1% 250VDC PHILIPS 2222 430 81002 10.350
C37-6 CAPACITOR MKT 22nF 5% 100VDC PHILIPS 2222 370 89223 11.169
C38-6 CAPACITOR POLYSTYRENE 3.3nF 1% 160V #PHILIPS 2222 429 83302 10.288
C39-6 CAPACITOR MKT 22nF 5% 100VDC PHILIPS 2222 370 89223 11.169
C40-6 CAPACITOR MKT 22nF 5% 100VDC PHILIPS 2222 370 89223 11.169
C41-6 CAPACITOR MKT 220nF 5% 63VDC PHILIPS 2222 370 79224 11.182
C42-6 CAPACITOR MKT 220nF 5% 63VDC PHILIPS 2222 370 79224 11.182
C43-6 CAPACITOR MKT 470nF 5% 63VDC ERO MKT 1826-447/06 4-G 11.187
C44-6 CAPACITOR MKT 220nF 5% 63VDC PHILIPS 2222 370 79224 11.182
C45-6 CAPACITOR MKT 220nF 5% 63VDC PHILIPS 2222 370 79224 11.182
C46-6 CAPACITOR CERAMIC 4n7F 20% CL2 50VDC KCK RT-HE80-SK YD 472 M 15.165
C47-6 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C48-6 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C52-6 CAPACITOR MKT 220nF 5% 63VDC PHILIPS 2222 370 79224 11.182
C53-6 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C54-6 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C56-6 CAPACITOR CERAMIC 4n7F 20% CL2 50VDC KCK RT-HE80-SK YD 472 M 15.165
C57-6 CAPACITOR ELECTROLYTIC 220uF -20/+50% 16VDC ERO EKM 00 CC 322 D G5 14.640
C58-6 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C59-6 CAPACITOR MKT 22nF 5% 100VDC PHILIPS 2222 370 89223 11.169
C60-6 CAPACITOR ELECTROLYTIC 220uF -20/+50% 16VDC ERO EKM 00 CC 322 D G5 14.640
C61-6 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C62-6 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C63-6 CAPACITOR ELECTROLYTIC 100uF -10/+50% 25VDC ERO EKM 00 CC 310 E G5 14.610
C64-6 CAPACITOR ELECTROLYTIC 220uF -10/+50% 40VDC ERO EKM 05 DE 322 G 05 14.648
C65-6 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C66-6 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C67-6 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C68-6 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C69-6 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C70-6 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C71-6 CAPACITOR CERAMIC 4n7F 20% CL2 50VDC KCK RT-HE80-SK YD 472 M 15.165
C72-6 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C73-6 CAPACITOR ELECTROLYTIC 220uF -20/+50% 16VDC ERO EKM 00 CC 322 D G5 14.640
C74-6 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ERO EKI 00 AA 210 F M5K 14.512
C75-6 CAPACITOR MKT 220nF 10% 63VDC PHILIPS 2222 370 78224 11.095
C76-6 CAPACITOR CERAMIC 4n7F 20% CL2 50VDC KCK RT-HE80-SK YD 472 M 15.165
C77-6 CAPACITOR MKT 470nF 5% 63VDC ERO MKT 1826-447/06 4-G 11.187
C78-6 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ERO EKI 00 AA 210 F M5K 14.512
C79-6 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ERO EKI 00 AA 210 F M5K 14.512
D1-6 TRANSIENT SUPPRESSOR 18V 1N6277A, PFZ18A, KE1.5KE1 MOTOROLA 1N6277ARL4 26.765
D2-6 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
D3-6 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
D4-6 DIODE GENERAL PURPOSE BAV21 200V/0.25A PHILIPS BAV21 25.340
D7-6 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
D8-6 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
D9-6 DIODE ZENER 5.1V 5% 0.4W BZX79C5V1 MOTOROLA BZX79C5V1 26.527
D10-6 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
D11-6 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
D12-6 DIODE HIGH SPEED 1N4448 PHILIPS 1N4448 25.147
D13-6 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D14-6 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D16-6 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
D17-6 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
D20-6 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
F1-6 FUSE 8AF 250V •5x20mm ELU 171 100 8AF 45.561
P1-6 PLUG MT 2 POLES AMP 0-826375-2 78.102
P2-6 PLUG MT 11 POLES AMP 1-826375-1 78.111
P3-6 PLUG MT 9 POLES AMP 0-826375-9 78.109
P4-6 PLUG MT 10 POLES AMP 1-826375-0 78.110
P5-6 PLUG MT 6 POLES AMP 0-826375-6 78.106
P6-6 PLUG MT 7 POLE AMP 0-826375-7 78.107
P7-6 MULTI PLUG 2x8 POLES PCB VERSION 3M 3599-6002 / 7616-6002 JL 78.249
