Sailor RT2047 User Manual

2 INSTALLATION RT2047 DSC - PART I
PAGE 2-4
2.3 DIMENSIONS AND DRILLING PLAN
UNIVERSAL MOUNTING BRACKET H2055
Permits a wide variety of installation possibilities, such as table top, bulkhead or deck head installation.
Fur other possibilities such as console installation, installation with 19" rack or assembly of all units in
the Compact programme on the bulkhead, see special information concerning installation of the
Compact programme.
132
132
225
115
132
min. 117
FE
D
B C
48
A
24894A
α
A B C D E F
0° 130 48 117 130 48 117
4.8° 142 48 117 146 53 117
9.6° 155 48 118 163 59 116
14.4° 167 45 133 178 65 113
WEIGHT
Mounting kit H2055 : 1.5 kg
H2054 : 5.5 kg
H2074 : 4.0 kg
CRY2001 : 3.2 kg
RT2047 : 5.2 kg
Dimensions in mm.
100 mm
80 mm
175 mm
50 mm
10 mm
4 pcs ø6.5 mm
4 pcs ø4.5 mm
132 mm C/F
24897
