Sailor RT2047 - Page 15

2 INSTALLATION RT2047 DSC - PART I
PAGE 2-5
4 pcs M5x8
24896
Mounting kit H2068 and H2055
132 132
48
132 225
215
D
A
B CFE
117
24895
α
A B C D E F
0° 230 67 117 230 67 117
4.8° 243 67 129 245 72 117
9.6° 255 65 142 262 78 115
14.4° 265 62 155 270 89 112
WEIGHT
Mounting kit H2068 and H2055 : 1.5 kg
H2054 : 5.5 kg
H2074 : 4.0 kg
CRY2001 : 3.2 kg
RT2047 : 5.2 kg
Dimensions in mm.
