2 INSTALLATION RT2047 DSC - PART I
PAGE 2-6
Mounting kit H2063
min.295
24898
4.5mm 4.5mm
16mm16mm 16mm
16mm
4 stk 6mm
4 stk 3.5mm uns for M3 DIN 963
Cutting out 231x100mm
253mm
240mm
100mm 113mm
27444A
Free distance must be kept to
allow free air circulation ambient
temperature max. 40°C.
WEIGHT
Mounting kit H2063 : 1.0 kg
H2054 : 5.5 kg
H2074 : 4.0 kg
CRY2001 : 3.2 kg
RT2047 : 5.2 kg
4 pcs M3x30
4 pcs cover
8 pcs M5x8
4 pcs M5x30
24770
