Sailor RT2047 - Page 17

2 INSTALLATION RT2047 DSC - PART I
PAGE 2-7
Mounting kit H2064
min.295
24772
240.00
4 stk ø6mm
4 stk ø3.5mm uns for M3 DIN 963
Cutting out 231x200mm
200mm 208mm 221mm
20mm20mm
4.5mm4.5mm
20mm20mm
253.00
27447A
Free distance must be kept to
allow free air circulation ambient
temperature max. 40°C.
WEIGHT
Mounting kit H2064 : 1.5 kg
H2054 : 5.5 kg
H2074 : 4.0 kg
CRY2001 : 3.2 kg
RT2047 : 5.2 kg
4 pcs M3x30
8 pcs cover
16 pcs M5x8
4 pcs M5x30
24899
