6 PARTSLIST RT2047 DSC - PART II
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
9810
PAGE 5-11
R141-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R143-6 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R144-6 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R145-6 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R146-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R147-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R148-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R150-6 RESISTOR MF 56k OHM 5% 0.4W PHILIPS 2322 181 53563 01.243
R151-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R152-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R153-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R154-6 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R155-6 RESISTOR MF 220k OHM 5% 0.4W PHILIPS 2322 181 53224 01.258
R156-6 RESISTOR 11 KOHM 1% 0.4W *PHILIPS 2322 156 11103 03.458
R157-6 RESISTOR MF 4k7 OHM 5% 0.4W PHILIPS 2322 181 53472 01.216
R158-6 RESISTOR MF 820 OHM 5% 0.4W PHILIPS 2322 181 53821 01.197
R159-6 RESISTOR MF 68 OHM 5% 0.4W PHILIPS 2322 181 53689 01.170
R160-6 RESISTOR MF 150 OHM 5% 0.4W PHILIPS 2322 181 53151 01.179
R161-6 RESISTOR MF 8k2 OHM 5% 0.4W PHILIPS 2322 181 53822 01.222
R162-6 PRESET CERMET 500 OHM 10% 0.5W BOURNS 3386P-Y91-501 07.885
RA1-6 RESISTOR ARRAY 8x10k OHM 5% 1/8W PANASONIC EXB-F9E-103 J 08.630
RA2-6 RESISTOR ARRAY 4x4k7 OHM 5% 1/8W BOURNS 4608X-102-472 08.625
RE3-6 RELAY E3206H EICHHOFF BV-55-280R 21.026
U1-6 VOLTAGE REGULATOR FIXED 5V/1A, MC7805, LM340T-5.0 MOTOROLA MC7805CT (MC7805BT) 31.250
U2-6 INTEGRATED CIRCUIT TDA2002V SGS* TDA2003 31.480
U3-6 DUAL OP AMP LM358N MOTOTOLA LM 358N 31.100
U4-6 8-STAGE SHIFT/STORE REG. MC14094, CD4094, MOTOROLA MC14094BCP 33.305
U5-6 DUAL OPERATIONAL AMP. MC1458/LM1458 MOTOROLA MC1458CP1 31.215
U6-6 TRANSISTOR ARRAY 3046 NATIONAL LM3046N 31.025
U7-6 QUAD VOLTAGE COMPERATOR LM339 NATIONAL LM339N 31.075
U8-6 EEPROM 2k BIT SERIAL NATIONAL NMC93C56N 32.710
U11-6 POW.DARLINGTON DRIVER x 7 ULN2003/MC1413 MOTOROLA MC1413P 31.077
U12-6 DUAL TYPE D FLIP-FLOP MC14013BCP MOTOROLA* MC14013BCP 33.056
U13-6 INTEGRATED CIRCUIT QUAD ANALOG SWITCH MOTOROLA MC14066BCP 33.233
U14-6 INTEGRATED CIRCUIT LF347N #NATIOPNAL LF347N 31.530
U15-6 DUAL DIFF.COMPARATOR LM393 TEXAS LM393P 31.105
U16-6 HEX INVERTERS 74HC04 TEXAS SN74HC04N 34.520
U17-6 QUAD OP.AMP. 324 NAT/SGS LM324N 31.065
U18-6 INTEGRATED CIRCUIT MC14569BCP * MOTOROLA MC14569BCP 33.449
U19-6 PROG. PROCESSOR U19 FOR 627746,INTERFACE,RT2047/D S.P.RADIO A/S C1112B - 2F60 728228
KEYBOARD UNIT MODULE 7/700 ECI A/S 5-0-27747C/4-0-27747B 627747
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C1-7 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C2-7 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C3-7 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C4-7 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C5-7 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C6-7 CAPACITOR MKT 220nF 20% 63VDC ERO MKT 1826-422/06 6-G 11.183
C7-7 CAPACITOR CERAMIC 27pF 5% N150 50VDC KCK RT-HE50-SK PH 270 J 15.076
C8-7 CAPACITOR CERAMIC 27pF 5% N150 50VDC KCK RT-HE50-SK PH 270 J 15.076
C9-7 CAPACITOR MKT 220nF 20% 63VDC ERO MKT 1826-422/06 6-G 11.183
C11-7 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C12-7 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C13-7 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C14-7 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C15-7 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C16-7 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C17-7 CAPACITOR CERAMIC 1n0F 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C18-7 CAPACITOR MKT 1u0F 10% 63VDC PHILIPS 2222 370 78105 11.137
D1-7 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
D2-7 DIODE LIGHT EMITTING ORANGE 5mm SANKEN SEL 1913K 25.631
D3-7 DIODE LIGHT EMITTING ORANGE 5mm SANKEN SEL 1913K 25.631
D4-7 DIODE LIGHT EMITTING YELLOW 5mm SANKEN SEL1910D 25.630
D5-7 DIODE LIGHT EMITTING YELLOW 5mm SANKEN SEL1910D 25.630
D6-7 DIODE LIGHT EMITTING ORANGE 5mm SANKEN SEL 1913K 25.631
D7-7 DIODE LIGHT EMITTING ORANGE 5mm SANKEN SEL 1913K 25.631
D8-7 LIQUID CRYSTAL DISPLAY COSTUM DESIGNED RT2047 STANDISH(HAMLIN SP TG.0-3-23886A 25.705
P1-7 MULTI PLUG 2x8 POLES PCB VERSION 3M 3599-6002 / 7616-6002 JL 78.249
