SAJ PDS33-2S2R2 User Manual

PDS33 Series
- 14 -
2.4.3 PDS33 Solar Controller Input and Output Data
PDS33-2SXX/4TXX Input and Output Data
Controller Model
PDS33-2S2R2
PDS33-4T2R2
PDS33-4T004
PDS33-4T5R5
Input Data
Max Input Voltage(Voc)
DC 450V
DC 800V
Recommended Voltage, at MPP
DC 275-380V
DC 500-750V
Recommended PV Array Power [kW]
2.7～3.5
2.7～3.5
4.8～6.4
6.6～8.8
Alternate AC Generator
Input Voltage
AC 220V(±15%)
Three Phase AC 380(±15%)
Max Amps(RMS)[A]
23
5.8
10.5
14.6
Power and VA Capability[kVA]
4
4
5.9
8.9
Output Data
Output Voltage, Rated
AC 220V(±15%)
Three Phase AC 380(±15%)
Max Amps(RMS)[A]
9.6
5.1
9
13
Output Power, Rated[kW]
2.2
2.2
4
5.5
Output Frequency
0～50Hz/60Hz
Controller Model
PDS33-4T7R5
PDS33-4T011
PDS33-4T015
PDS33-4T18R5
Input Data
Max Input Voltage(Voc)
DC 800V
Recommended Voltage, at MPP
DC 500-750V
Recommended PV Array Power[kW]
9～12
13.2～17.6
18～24
22.2～29.6
Alternate AC Generator
Input Voltage
Three Phase AC 380V(±15%)
Max Amps(RMS)[A]
20.5
26
35
38.5
Power and VA Capability[kVA]
11
17
21
24
Output Data
Output Voltage, Rated
Three Phase AC 380V(±15%)
Max Amps(RMS)[A]
17
25
32
37
Output Power, Rated[kW]
7.5
11
15
18.5
Output Frequency
0～50Hz/60Hz
