PDS33 Series
- 48 -
6.3 Description of controller’s status and faults
Description
Communication
address
Command content
Attributes of
read or write
Controller’s
status
3000H
0001：FWD running
0002：REV running
0003：Stand-by
0004：Fault
0005：Under voltage
0006：Exchanging between
R
Controller’s
fault
8000H
0000：No error
0001：Reserved
0002：Over current during
acceleration
0003：Over current during
deceleration
0004 ： Over current at
constant speed
0005：Over voltage during
acceleration
0006：Over voltage during
deceleration
0007 ： Over voltage at
constant speed
0008 ： Overload of buffer
resistor
0009：Under voltage error
000A：Controller overload
000B：Motor overload
000C：Input phase loss
000D：Output phase loss
000E：Module overheat
000F：External error
0010 ： Communication
abnormal
0011：Relay failure
R
