SAJ R5-0.7K-S1 User Manual

R5 Series
- 15 -
R5-3K/3.6K/4K/5K/6K-S2
Type
R5-3K-S2
R5-3.6K-S2
R5-4K-S2
R5-5K-S2
R5-6K-S2
Input (DC)
Max. PV Array Power [Wp]@STC
4500
5520
6000
7500
9000
Max. DC Voltage [V]
600
MPPT Voltage Range [V]
90-550
Nominal DC Voltage [V]
360
Start Voltage [V]
100
Min. DC Voltage [V]
80
Max. DC Input Current [A]
12.5/12.5
Max. DC Short Current [A]
15/15
Number of DC Connection Sets per MPPT
1/1
Number of MPPT
2
DC Switch
Integrated
Output (AC)
Rated AC Power [W]
3000
3680
4000
4600
1
/5000
2/
5000
6000
Max. AC Power [VA]
3300
3680
4400
4600
1
/5000
2/
5500
6000
Rated AC Current [A]@230Vac
13.1
16
17.4
20/21.8/21
.8
26.1
Max. AC Current [A]
14.4
16
19.2
24/24/24
26.1
Nominal AC Voltage/Range [V]
220,230,240/180-280
Grid Frequency/ Range [Hz]
50,60/45-55,55-65
Power Factor [cos φ]
0.8 leading~0.8 lagging
Total Harmonic Distortion [THDi]
< 2%
Feed-in
L+N+PE
Efficiency
Max. Efficiency
97.8%
98.0%
98.0%
98.1%
98.2%
Euro Efficiency
97.2%
97.5%
97.5%
97.6%
97.6%
MPPT Accuracy
>99.5%
Protection
Internal Over-voltage Protection
Integrated
DC Insulation Monitoring
Integrated

SAJ R5-0.7K-S1 Specifications

General

Brand	SAJ
Model	R5-0.7K-S1
Category	Inverter
Language	English
