Please note:
3
Wiring diagram for control box connection:
N L
N
1-8 Zones
SLL
S1
S2
L
N
AC 230V
Power
NO
N L
COM
Legend:
Boiler connection * - Boiler’s contacts
for ON/OFF thermostat (according to the
boiler’s instructions)
Pump
Boiler
Valve actuator
Heating mat
KL08
NSB
Self-acting SQ610 Quantum Thermostat without application support can be easily added to the
Smart Home app anytime. All settings made before adding to the application are automatically
copied to the Smart Home app.
