Salus VS10B - Hot Water Timer Wiring

Installation – Hot Water Timer wiring
Power Connections 230 Vac
Optional
Communication
Connections 12 VDC
If hot water is part
of a group then the
communication
connection must
be connected to
group 1.
18 VS10W and VS10B Installer Manual
