Installation – Thermostat Mounting
Check that the wiring is completed for:
1
2
3
Please use the screws provided
Ensure the orientation arrow
is pointing upwards.
Power Terminals
Sensor Terminals (if applicable)
Communication connections (optional but recommended)
You are ready to secure the rear housing to the wall box
20 VS10W and VS10B Installer Manual
