Installation – LCD Graphics
ICON FUNCTION
Floor sensor probe indicator
Show only when Air + Floor sensor is connected.
Low battery indicator:
Batteries need to be replaced.
Setting indicator:
Indicate the unit is in setting mode when program setting.
Indicate the manual mode.
Keylock indicator:
Shows that keys are inactive.
VS10W and VS10B Installer Manual 25
INSTALLATION
