49 VS20WRF and VS20BRF Installer Manual
Installation - Pairing with System Receiver RX1 only
Checklist
1
The coordinator or the universal gateway must be in
pairing mode.
2
The system receiver (Configured to RX1) is powered up
and the red LED will flash when the pairing is in process
and will be steady when the pairing is complete.
System Receiver configured to boiler receiver RX1.
Refer to system receiver manual.
Used when you want multiple thermostats to activate the same receiver
Used if system receiver is used on its own.
*Set your system parameters by following the steps on pages 5-6.
Pairing without Internet connection using a CO10RF or a UG600/
UGE600
5 sec
5 sec
To Next Page
