74 VS20WRF and VS20BRF Installer Manual
Installation - Device Parameters continued
DX FUNCTION SYSTEM SETTING DEFINITION DEFAULT
D07 Valve protection 0 Disable
1
1 Enable
D08 Frost Set point 5-17 Deg C Required Temperature for frost 5 Deg
Temperature protection and holiday mode
D09 Hour Format 0 12
1
1 24
D10 N/A N/A N/A N/A
D11 Daylight Saving 0 OFF
1
Time (DST) 1 ON
D12 Heating Set point
5-35 Deg C
Maximum temp that can
35 Deg C
Limit be set for heating
D13 Cooling Set point
5-40 Deg C
Maximum temp that can
5 Deg C
Limit be set for Cooling
D14 Floor sensor High Output relay will be switched off
Limit Temperature 6-40 Deg C when temp is reached for 27 Deg C
floor protection
D15 Floor sensor Low Output relay will be switched on
Limit Temperature 6-40 Deg C when temp is reached for 10 Deg C
floor protection
D16 Floor sensor Limit Output relay will be switched off
for cooling 6-40 Deg C when temp is reached for 6 Deg C
floor protection
