Sam4s SAP-630 Series User Manual

2 Product Specifications
SAM4S SAP-630 SERIES 2-3
2-3 Thermal Printer Specifications
2-3-1 Printer Specification (3”)
Item Description Remark
Model
 LTPF347E
SII
Print Method
 Thermal Line Printing
Printing Format
Total Number of Dots
 576 Dots / I Line
Dot Pitch
 Vertical : 0.125 mm
 Horizontal : 0.125 mm
Printing Speed
 100 mm/Sec
Printing Direction
 Unidirectional Friction Feed
Paper Feeding
Feeding Method
 Friction Feed
Minimum Feed Pitch
 0.0625 mm
Feeding Speed
 100 mm/Sec
Power Supply Volt
Power Voltage
 24V/24V (Recommend)
Head/Motor
Circuit Input Voltage
 5V
Head Control/Sensor
Printer Head
Heat Element Density
 8 Dots/mm (200dpi)
Total Head Elements
 576 Dots/Dot Line
Available Printing Width
 72 mm
Heat Element Typical Ω  1500 Ω ±3%
Line Feed Motor
 4-Phase Bi-Polar Stepping Motor
Sensor
Head Temperature
 Thermistor
Paper-End Sensor
 Reflecting Photo Sensor
Printer Cover Open Sensor
 Micro Switch
Auto Cutter Type
 Guillotine Type
SII
Reliability
TPH
 100Km , 1×10
8
Pulses
Auto-cutter
 1,000,000 Cuts
Paper : PD-160R-N
(Oji paper co.,Ltd)
Dimension (mm)
 110.2 (W) ×54 (D) ×25.8 (H)
Weight
 Approx. 175 g
Table2-2 Thermal Printer Specifications
