SAM4S SAP-630 SERIES 2-1
2 Product Specifications
Specifications are correct at the time of printing. Product specifications are subject to change without notice.
See below for product specifications.
General Specifications
Item Description Remark
PROCESSOR  Intel Celeron N3160(Quad Core up to 2.24GHz)
OS  Android 6.0(Marshmallow)
MEMORY
 Storage : eMMC 8GB
 SDRAM : DDR3 2GB
SERIAL
INTERFACE
(RS-232C)
 Flow Control :
① CTS / RTS : H/W Flow Control
② XON / XOFF : S/W Flow Control
 Voltage Supply : VCC(+5V/1A) supplies at RS-232C#1~#4
RS-232C #1(DSUB-9)
RS-232C #2(DSUB-9)
RS-232C #3(RJ45)
RS-232C #4(RJ45)
LAN
 10/100 base-T
ETHERNET(TCP/IP)
SD CARD  1-Slot [64GB_max] SDHC Compatible
MSR  1-Slot [option] 1/2 Track or 2/3 Track
i-BUTTON  Magnetic [option]
DRAWER  3-port [ Default (internal) #1 / RJ-11 #2,#3]
USB  2-port [HOST]
WIRELESS  WiFi / Bluetooth [option]
PRINTER
 Model : LTPF347E(SII)
 Printing Speed : 100mm/sec
Detail Spec refer to Next
Page
AUTO CUTTER
 Type : Guillotine
 Cutting Method : 1 Point Partial Cutting
DISPLAY
 Operator Display : 9.7” TFT-LCD(LED B/L), 1024x768
 Customer Display : 16char*2line LCD
TOUCH  5-Wire Resistive
KEY BOARD
 Flat Rubber Key : 160 Key
 Raised Key : 90Key
POWER
CONSUMPTION
 Approx. 40W (Regularity)
POWER
REQUIREMENT
 AC 100-240V 50/60Hz
ENVIRONMENT
CONDITION
 Temperature : 0℃ ~ 45℃
 humidity : 30% ~ 80% RH
WEIGHT  Approximately 12Kg
DIMENSION(mm)
 400(W) × 468(L) × 344(H) : With G-Drawer
Set Size
Table2-1 General Specifications
