Sam4s SAP-630 Series User Manual

2 Product Specifications
2-4 SAM4S SAP-630 SERIES
2-3 Thermal Printer Specifications
2-3-2 Paper Specification
Item Description Remark
Paper Type
 Single-ply Thermal Paper Roll
Paper Size  79.5 mm±0.5 mm (Width) ×80 mm or less
Specified Paper
 Original Paper No : HPK-110 (Hansol paper XT)
Table2-3 Paper Specification
Note: The following paper can be used instead of the specified paper above.
TF50KS-E: Nippon paper industries Co.,Ltd.
PD 160R : New Oji paper Mfg, Co.,Ltd.
F380 : Kansaki specialty papers, Inc. (USA)
2-3-3 Printable Area
The Printable area of a paper with width of 79.5mm is 72.0mm(576 dots) and the space on the right and left
sides are approximately 4.0mm.
Figure2-3 Printable Area
2-3-4 Character Specification
Item Description Remark
Character Structure
 12(W) × 24(H) Font (Including a Horizontal)
Character Size
 1.25 mm(W) ×3.0 mm(H)
Column Pitch
 1.5 mm
Line Pitch
 3.75 mm (Including 6-dot Line Spacing)
Number of Column
 32 (12×24 Dots/Character)
Table2-4 Character Specification
b
c d e
a
a = 79.5±0.5 mm (Paper Width)
b = 0.141
mm ( 1 Dot )
c = 72.0
mm (576 Dots/Printable Area)
d = 4.0
mm (Left Space)
e = 4.0
mm (Right Space)
