12 | SAMLEX AMERICA INC.
APPENDIX A
SECTION 3 | Operation
a) The rst character of the right-hand corner display indicates the code for the Charging Prole that is active:
i. Numeral 0 to 5 for 6 options for 3-Stage / 2-Stage Charging Proles (Refer to Section 4.4.2.21 for details), or
ii. Letter “E” for 4-Stage Adaptive Prole for Equalization (Refer to Section 4.4.2.12)
b) The other portion of the right-hand corner display provides the following coded information pertaining to the
Charging Stage that is active:
• CC for Constant Current Stage
• CV for Constant Voltage 2
nd
Stage in 3-Stage / 2-Stage Charging Proles
• E-CVA for Constant Voltage Absorption Stage in 4-Stage Adaptive Charging Prole for Equalization
• E-CVE for Constant Voltage Equalization Stage in 4-Stage Adaptive Charging Prole for Equalization
• FLOAT for Float Stage
• OFF for charger off
Consolidated information related to the 1
st
line right hand corner display is given in Table 3.2 below:
TABLE 3.2 Codes / Abbreviation used in Charging Mode screens for Display of Charging Proles / Charging Stages
1
st
line, right corner
display under “GROUP
3: CHARGING MODE”
screens in Fig 3.2
Description
0-CC Constant Current, Bulk Stage, Parameter CHARGING PROFILE option : 0=3Stg Adaptiv
1-CC Constant Current, Bulk Stage, Parameter CHARGING PROFILE option : 1=3Stage Type1
2-CC Constant Current, Bulk Stage, Parameter CHARGING PROFILE option : 2=3Stage Type2
3-CC Constant Current, Bulk Stage, Parameter CHARGING PROFILE option : 3=2Stage Type1
4-CC Constant Current, Bulk Stage, Parameter CHARGING PROFILE option : 4=2Stage Type2
5-CC Constant Current, Bulk Stage, Parameter CHARGING PROFILE option : 5=2Stage Type3
E-CC Constant Current, Bulk stage of 4-Stage Adaptive Prole for Equalization
0-CV Constant Voltage, Absorption stage, Parameter CHARGING PROFILE option : 0=3Stg Adaptiv
1-CV Constant Voltage, Absorption Stage, Parameter CHARGING PROFILE option : 1=3Stage Type1
2-CV Constant Voltage, Absorption Stage, Parameter CHARGING PROFILE option : 2=3Stage Type2
3-CV Constant Voltage, Absorption Stage, Parameter CHARGING PROFILE option : 3=2Stage Type1
4-CV Constant Voltage, Absorption Stage, Parameter CHARGING PROFILE option : 4=2Stage Type2
5-CV Constant Voltage, Absorption Stage, Parameter CHARGING PROFILE option : 5=2Stage Type3
E-CVA Constant Voltage, Absorption Stage of 4-Stage Adaptive Prole for Equalization
E-CVE Constant Voltage, Equalization Stage of 4-Stage Adaptive Prole for Equalization
0-FLOAT Float Stage, Parameter CHARGING PROFILE option : 0=3Stg Adaptiv
1-FLOAT Float Stage, Parameter CHARGING PROFILE option : 1=3Stage Type1
2-FLOAT Float Stage, Parameter CHARGING PROFILE option : 2=3Stage Type2
3-OFF Charger Off, AC bypass, Parameter CHARGING PROFILE option : 3=2Stage Type1
5-OFF Charger Off, AC bypass, Parameter CHARGING PROFILE option : 5=2Stage Type3
CHGR STOP BY BMS
Charging switches off when Pins 4 and 5 of Battery Temperature Sensor Jack (6 in Fig 2.1 of Manual for EVO-
2212/3012/2224/4024) are shorted by control signal from Lithium Ion Battery Management System (BMS).
(For details, please refer to Section 5.11.2 of the attached Owner’s Manual for EVO-2212/3012-2224/4024)
For example, in Fig 3.2, the 1
st
line of information under Column 4 (GROUP 3: CHARGING MODE) shows “0-CC” in the
right corner. This means that the unit is charging under the following conditions:
• CHARGING PROFILE: Option “0=3Stg Adaptiv” i.e. 3-Stage Adaptive Charging Prole (Refer to Section 5.7 of the
attached Owner’s Manual for EVO/2212/3012/2224/4024 for details on this prole)
• Charging Stage: “CC” i.e. Constant Current Bulk Stage
