APPENDIX A
Table 6.1 LED & BUZZER INDICATIONS FOR OPERATION MONITORING
Status Green LED "Status" Red LED "Fault" Buzzer (See Note 1)
Seen during Power-On Sequence
Refer to Section 3.2.1
Blink 3 times & then
turn off
OFF OFF
Seen during Power-Off Sequence
Refer to Section 3.2.2
ON ON OFF
Normal charging Blink once in 1 sec
interval
OFF OFF
Equalization charging Blink twice in 1 sec
interval
OFF OFF
Inverting ON OFF
Beep once in 3 sec
interval
Low battery alarm ON Blink once in 1 sec
interval
Beep once in 1 sec
interval
Power saving Blink once in 3 sec
interval
OFF OFF
Standby Blink once in 5 sec
interval
OFF OFF
Fault OFF ON ON
NOTE:
1. Buzzer is available only in EVO™ Inverter/Charger. There is no buzzer in Remote Control EVO-RC.
